Roofing Sheets

We are Specialised in PPGI and PPGl sheets which are made of world clss raw material complying to the international Standards. Because of its excellent corrosion resistance, these sheets have become the most preferred material for various construction purpose particularly roofing and walling. Coated steel sheet is a unique building material that combines the strength of steel with excellent corrison protection of zinc or Zinc /Aluminium alloy coating. It can be punched, pressed, roll –formed and jined in to a countless number of structural and decorative building products.

With our expertise in this Domain, we are able to offer Superior Quality Roofing System. These are ligtht weight Wide Spam Trapezoidal Shaped With 26 mm Rib epth, width 255 mm that are pitch strengthened by two stiffness to allow easy water shredding Suiting to heavy rain industrial area.

More over, before the end delivery, our range is stringently checkd by the quality analyzers of our firm to ensure its flawless ness.

Available Colors





Techinical Specfication :

  • Trough Depth: 26mm
  • Pitch : 255 mm
  • Supplied width: 1120 mm
  • Covered width : 1020 mm
  • Thickenss Range :0.3 to 0.8 mm
  • Length :up to 12 meters

Advantages :

  • Single - Source Responsibility
  • Faster Instillation
  • Overall Economical
  • Factory - controlled quality (ISO 9001 Certified)
  • Practically maintenance free
  • Up to 60 M clear spans
  • Flexibility in expansion
  • Energy efficient roof and well systems

Material Specification :

Zinc Alum Steel Sheet (bare-galvalume) Non-color (55% Aluminium, 43.4% Zinc, 1.6% Silicon) AI-Zinc Coating AZ 150


    Yield Strength 550 Mpa Thickness Ranging from 0.47mm TCT -0.50mm TCT

Pre-painted Galvanized Steel sheets (PPGI)

  • Zinc Coating Z120, Z180, Z275
  • Paint Coating RMP/SMP
  • Painting Thickness(Top) 18-20 microns
  • Painting Thickness(Bottom) 5-7 microns Alkyd backed coat
  • Surface paint reflection Glossy finish(optional - Matt finish)
  • Yield Strength 240 Mpa Thickness Ranging From 0.47mm TCT - 0.50mm TCT

Pre-painted Galvalume Steel sheet (Alu - Zinc alloy coated) (55% Alluminium, 43.4% Zinc, 1.65 Silicon)

  • Zinc Coating AZ 150
  • Paint Coating Regular Modified Polyester(RMP)/Silicon Modifies Polyster(SMP)
  • Painting Thickness (Top) 18-20 microns
  • Painting Thickness (Bottom) 5-7 microns Alkyd backed coat
  • Surface paint reflection Glossy finish(optional - Matt finish)
  • Color Coated Galvalume 550Mpa Thickness Ranging From 0.47mm TCT - 0.50mm TCT

The cold rolled steel sheets are galvanized and painted with RMP/SMP/HDP/PVF2 and the basic steel confirms to IS 277 with zinc coating 120 GSM (ASTM A653, A755, JIS G3302, G3312, IS277, 513, 14246, AS1397). These are available in different sizes as per client specification.

Curve Sheets:

We manufacture curve sheets which is also called as crimping Sheets up to 8 meters. We do also manufacture supporting accessories which are necessary for an industrial sheds




  • Watter gutters
  • Down spots
  • Barge cap
  • Ridges
  • Corner flashings
  • Drip trim

Our product are well known for the following factors :

  • Perfect Finish
  • Flawlessness
  • Available in vivid colors
  • Available in Several dimensions

Benefits of using color coated Roofing Sheets :

  • Study constructions
  • Low cost
  • Weather resistance
  • Corrission resistance
